RG-PD150IB-F is AC input (support LVDC) and DC output, and provides 12 V output voltage. The maximum voltage can
reach 150 W.
The switch can be powered by one power supply module, or two power supply modules. When both two modules are
working, the switch is working in power redundancy mode.
1.6.1 RG-PA150I-F and RG-PA150IB-F

Specification

Power Model
Device Model
Rated Voltage
Maximum Voltage
Input Current
Output Voltage
Max Current Output
Max Power Output
Input Leakage
Current
Dimensions
(L x W x H)
Weight
Temperature
Humidity
Altitude
Features
Feature
Conformal Coating
RG-PA150I-F, RG-PA150IB-F
RG-S5760C-48GT4XS-X
RG-S5760C-24GT8XS-X
RG-S5760C-24SFP/8GT8XS-X
AC input:
100 to 240 V AC
50/60 Hz
HVDC input:
240 V DC
AC input:
90 to 264 V AC
47/63 Hz
HVDC input:
192 to 288 V DC
3 A max
12 V
12.5 A
150 W
3.5 mA max
196 mm x 50.5 mm x 40mm (7.72 in. x 1.99 in. x 1.57 in.)
0.55 kg (1.21 lbs.)
Operating temperature: -10° C to 55° C (14° F to 131° F)
Storage temperature: -40° C to 70° C (-40° F to 158° F)
Operating humidity: 5% to 95%
Storage humidity: 5% to 95%
0 m to 5,000 m (3.11 miles)
Description
Protects circuits against moisture, frog, mould, electrical shock and leakage, and so
on.
