Ruijie RG-S5760C-X Series Hardware Installation And Reference Manual page 23

Hardware Installation and Reference Guide
Protection
I2C Communication
Power Supply Redundancy
Hot Swapping
Power Supply Alarm
LED
LED State
Output Status Off
LED
On
1.6.2 RG-PD150IB-F
Specification
Power Model
Device Model
Rated Voltage
Input Current
Output Voltage
Max Power Output
Dimensions
(L x W x H)
Weight
Temperature
Humidity
Altitude
Features
Feature
Conformal Coating
Protection
Provides protection over over-voltage/current input/output, short-circuit output and so
on.
Allows the host to communicate with the power supply module by I2C.
Supports dual power supply modules to cooperate in parallel, enabling PE with 1+1
redundancy and redundant power supplies with current sharing.
Supports to disconnect one redundant power supply module from the outside power
supply system, plug and unplug power supply modules while the device is powered
on.
Alarms power supply faults through the power supply status LED.
RG-PD150IB-F
RG-S5760C-48GT4XS-X
RG-S5760C-24GT8XS-X
RG-S5760C-24SFP/8GT8XS-X
DC input:
-48 to -60 V DC
5 A max
12 V
150 W
196 mm x 50.5 mm x 40mm (7.72 in. x 1.99 in. x 1.57 in.)
0.55 kg (1.21 lbs.)
Operating temperature: -10° C to 55° C (14° F to 131° F)
Storage temperature: -40° C to 70° C (-40° F to 158° F)
Operating humidity: 5% to 95%
Storage humidity: 5% to 95%
0 m to 5,000 m (3.11 miles)
Description
Protects circuits against moisture, frog, mould, electrical shock and leakage, and so
on.
Provides protection over over-voltage/current input/output, short-circuit output and so
on.
Meaning
There is no power output or output fault occurs.
Power output is normal.
20
Overview
