Hardware Installation and Reference Guide
LED
LED
System LED
Power supply status
LED
MGMT port status
LED
10GE SFP+ port
status LED
10/100/1000Base-T
Ethernet port status
LED
Panel Identification
Status
PWR1/PWR2
MGMT
25F-32F
1-24
Status Meaning
Off The switch is not powered on.
Blinking green Initialization is in progress. Continuous blinking
(3 Hz) indicates a fault.
It is used for on-site positioning of the device,
Blinking green (10 and allows operation and maintenance
Hz) personnel to perform remote power on and off
control.
Solid green The switch is operational.
Temperature alarm:
1. The temperature of inlet/outlet vent exceeds
the warning threshold.
Solid yellow
2. The power is insufficient for the system.
Check the working environment of the switch
and power supplies immediately.
1.
Solid red
2.
The power supply module is not in place or not
Off
powered on.
The power supply module is operating
Solid green
normally.
The power model is identified but not
Solid yellow
recognized.
The redundant power is faulty or the AC power
Solid red
cord is not connected.
Off The port is not connected.
Solid green The port is connected at 1000 Mbps .
The port is receiving or transmitting data at
Blinking green
1000 Mbps.
Solid yellow The port is connected at 10/100 Mbps.
The port is receiving or transmitting data at
Blinking yellow
10/100 Mbps.
Off The port is not connected.
Solid green The port is connected at 1/10 Gbps.
The port is receiving or transmitting data at
Blinking green
1/10 Gbps.
Off The port is not connected.
Solid green The port is connected at 1000 Mbps .
The port is receiving or transmitting data at
Blinking green
1000 Mbps.
Solid yellow The port is connected at 10/100 Mbps.
6
The temperature of the inlet/outlet vent
exceeds the warning threshold.
The switch is faulty.
Overview
