Parameter Table (continued)
3.1-3
Parameter
Number
Printout format for com1 and com2
28
Printout format for com2.1
29 Header lines added
Baudrate com2
30
Baudrate com2.1
Setting com2
31
Setting com2.1 & 2.2
32
End Character com2.2 only
34 End character com2
35 Protocol com2
36 Number of linefeeds com2
37 Handshake com2
38 Print Twice
39
Protocal com2.2 only
40 Level sensor
41 Delay trigger time level sensor
43 Compensation factor correction factor
44 Compensation factor X-direction
45 Compensation factor Y-direction
49 Underload percentage of FS
60 Battery used
61 Low Bat switch-off time
62 Auto shut-off time indicator
NOTE: Com2.1 is used with a printer and Com2.2 is used for bluetooth communication to a PDA.
A
Some software versions may only have options 1 through 5 available
B
Some software versions may not offer this parameter.
C
6823346-R3
Function
2.15 & before
A
2.15 & before
A
2.15 & before
A
A
A
Default Settings
Software
Version EU US
stnd stnd
2.18
0 0
9600 9600
2.18
8_n_1 8_n_1
2.18
2.18 cr cr
cr cr
0 0
B
4 4
soft soft
0 0
C
2.18 None None
no/ls no/ls
3 3
1 1
1 1
1 1
002 002
6 6
2 2
2 2
Available Setting Options
stnd, total, confi
0 – 3
600, 1200, 2400, 4800, 9600, 19200
8_n_1, 8_n_2, 7_n_1, 7_n_2
cr, lf, crlf
cr, lf, crlf
0 = PC bi-directional NU
1 = PC Excel format on print command
2 = remote display
3 = printer protocol with power control
4 = printer protocol without power
control
5 = Not used
6 = PC Excel format with ack/nack
7 = Mobile barcode printer
8 = Scanner serial prot.
0 – 9
soft (Xon/Xoff), hard (CTS)
0 = Print only once
1 = Print twice
None, 0 (PC bidirectional)
NOTE: This is automatically set based
on parameter 35 setting.
no/ls, nc/ls, no/cs, ra/cs, ls
0 – 10 sec
0.1 – 10.0
0.1 – 10.0
0.1 – 10.0
0%-100%
6V, 12V
0 = never off, 1 – 99 minutes
0 = never off, 1 – 99 minutes
