Changing A Parameter's Setting
3.1-2
NOTE: Refer to the Parameter Table (Section 3.1-3) on the
following pages to determine the parameter number.
1
Access the Parameters Menu as described in Section
3.1-1.
2
Enter the parameter number of the parameter setting to
change. Use the Entry Mode Guide (below) as an aid
to change the parameter number (A and B). Always
accept the value by pressing the "Zero" button, C.
C
3
Press the "Zero" button to enter the selected parameter.
4
Refer to the "Available Setting Options" column, found
on the Parameter table (Section 3.1-3) on the following
pages, to determine if the current setting should be
changed and setting the options available.
Example:
Parameter
01 Weight units
02 Smallest graduation step for multirange
03 Biggest graduation step for multirange
FK0249.eps
Selected Parameter Row
20
Entry Mode Guide
Selected value will flash
A
Function
FK0252.eps
The following buttons are available
while in Entry Mode:
A
Decrease
the Value
B
B
Shift to the next
digit on the left
FK0248.eps
Default Settings
EU US
kg lb kg, lb
1 2 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50
2 5 0.1, 0.2, 0.5, 1, 2, 5, 10, 20, 50
Current Settings
2
OR
Increase the
Value
C
Accept the value
(press last)
FK0246.eps
3
Setting Options Column
Setting Options
Setting Options Available
