Wire Harness - Ravas iForks Service Manual

T
ROUBLESHOOTING

Wire Harness

2.4-2
14
Start
With fully charged batteries
and the iFork assemblies
switched on, check the
voltage of battery holder.
YES
Voltage
6 VDC
NO
Battery holder is faulty,
replace wire harness
Check cables, especially where the
cable enters the load cell connector.
Move the cable and observe the display.
YES
Display
reacts
NO
Check load cell calibration board.
Without touching contact points,
move board or cables.
YES
Display
reacts
NO
Complete
FK0121.eps
Cable or connector
is damaged or has
oxidized
Contact is bad
