Chapter 1: Overview
Board Component Blocks
© March 2010 Altera Corporation
Downloaded from Elcodis.com electronic components distributor
■ General user I/O
LEDs and display
■
Four FPGA user LEDs
■
One configuration done LED
■
One max error LED
■
Five Ethernet status LEDs
■
One USB status LED
■
One power status LED
■
Two PGM LEDs
■
A two-line character LCD display
■
Push-Button switches
■
One CPU reset push-button switch
■
One MAX II configuration reset push-button switch
■
One PGM configure push-button switch (configure the FPGA from flash
■
memory)
One PGM select push-button switch (select image to load from flash
■
memory)
Two general user push-button switches
■
DIP switches
■
Board setting DIP switch
■
Configuration setting DIP switch
■
■ Power supply
9-V – 16-V DC input
■
2.5-mm barrel jack for DC power input
■
On/Off slide power switch
■
On-Board power measurement circuitry
■
Mechanical
■
6.6" x 2.713" board
■
PCI Express chassis or bench-top operation
■
