Fig. 8 Normally Open FACP Latching trigger input with reset (This output has not been evaluated by UL):
FACP
TRG
Fig. 9 Normally Closed: Non-Latching FACP trigger input:
FACP
TRG
Fig. 10 Normally Closed: Latching FACP trigger input with reset (This output has not been evaluated by UL):
FACP
TRG
- 12 -
Hook-Up Diagrams:
N.O.
TRIGGER
INPUT
JUMPER
N.C. DRY
TRIGGER
JUMPER
N.C. RESET
SWITCH
JUMPER
N.C. RESET
SWITCH
INPUT
N.C. TRIGGER
INPUT
