Power Supply Board Led Diagnostics; Access Power Controller Led Diagnostics; Power Supply Board Terminal Identification - Altronix Maximal3F Installation Manual

Red (DC)
ON
ON
OFF
OFF
Red (Bat)
ON
OFF
LED
LED 1- LED 8 (Red)
Trg (Green)

Power Supply Board Terminal Identification:

Terminal Legend
L, G, N
+ DC –
Trigger EOL
Supervised
NO, GND
RESET
+ AUX –
AC FAIL
NC, C, NO
BAT FAIL
NC, C, NO
+ BAT –
Maximal3F/Maximal5F/Maximal7F Access Power Controllers (Fused)

Power Supply Board LED Diagnostics:

Green (AC/AC1)
ON
OFF
ON
OFF
Battery Status
Normal operating condition.
Battery fail/low battery.

Access Power Controller LED Diagnostics:

ON
Output relay(s) energized.
FACP input triggered (alarm condition).
Function/Description
Connect 120VAC 60Hz to these terminals: L to hot, N to neutral.
Do not use terminal marked [G].
Factory connected to ACM8 board.
Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally
open, normally closed from an FACP output circuit (Class 2 power-limited input)
(Fig. 3, pg. 10).
FACP interface latching or non-latching (Class 2 power-limited) (Fig. 3, pg. 10).
Auxiliary Class 2 power-limited output rated @ 1A (unswitched) (Fig. 3, pg. 10).
Indicates loss of AC power, e.g. connect to audible device or alarm panel.
Relay normally energized when AC power is present.
Contact rating 1A @ 30VDC (Class 2 power-limited) (Fig. 3, pg. 10).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1A @ 30VDC.
A removed battery is reported within 5 minutes.
Battery reconnection is reported within 1 minute (Class 2 power-limited) (Fig. 3, pg. 10).
Stand-by battery connections.
Maximum charge current 1.54A (non power-limited) (Fig. 3, pg. 10).
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery is supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
OFF
Output relay(s) de-energized.
FACP normal (non-alarm condition).
- 7 -
