2

Specifications

2.1

Core System

CPU: 6th Generation Intel® Core™, Celeron® and Xeon® E3-15xx v5 processor (formerly "Skylake-H")
Intel® Xeon® E3-15xx v5 45W/35W(cTDP) (4C/GT4e)
Intel® Xeon® E3-1505M v5 2.8/3.7GHz (Turbo), 0.35/1.0GHz (Turbo), 45W/35W(cTDP) (4C/GT2)
Intel® Xeon® E3-1505L v5 2/2.8GHz (Turbo), 0.35/1.0GHz (Turbo), 25W (4C/GT2)
Intel® Core™ i7-6820EQ 2.8/3.5GHz (Turbo), 0.35/1.0GHz (Turbo), 45W/35W(cTDP) (4C/GT2)
Intel® Core™ i7-6822EQ 2/2.8GHz (Turbo), 0.35/1.0GHz (Turbo), 25W(4C/GT2)
Intel® Core™ i5-6440EQ 2.7/3.4GHz (Turbo), 0.35/1.0GHz (Turbo), 45W/35W(cTDP) (4C/GT2)
Intel® Core™ i5-6442EQ 1.9/2.7GHz (Turbo), 0.35/1.0GHz (Turbo), 25W (4C/GT2)
Intel® Core™ i3-6100E 2.7GHz, 0.35/1.0GHz (Turbo), 35W (4C/GT2)
Intel® Core™ i3-6102E 1.9GHz, 0.35/1.0GHz (Turbo), 25W (4C/GT2)
Intel® Celeron® TBD (2C/GT1)
Supporting: Intel® VT, Intel® TXT, Intel® SSE4.2, Intel® HT Technology, Intel® 64 Architecture, Execute Disable Bit, Intel® Turbo Boost Technology
2.0, Intel® AVX2, Intel® AES-NI, PCLMULQDQ Instruction, Intel® Device Protection Technology with Intel® Secure Key, Intel® TSXNI
Note: Availability of features may vary between processor SKUs.
Cache: 8MB for Xeon®/Core™ i7, 6MB for Core™ i5, 3MB for Core™ i3 and 2MB for Celeron®
Memory: Dual channel ECC/non-ECC 1866/2133 MHz DDR4 memory up to 32GB in dual stacked SODIMM sockets
Chipset: Mobile Intel® QM170, HM170 and CM236 Chipset (HM170 does not support Intel® AMT)
Embedded BIOS: AMI EFI with CMOS backup in 8 MB SPI BIOS with Intel® AMT 11 support
CPU and Chipset Combinations
Express-SL (non-ECC memory support)
Core™ i7/i5 with QM170 Chipset
Core™ i3/Celeron® with HM170 Chipset
Express-SLE (ECC memory support)
Xeon® with CM236 Chipset
Core™ i3/Celeron® with CM236 Chipset (available with MOQ)
2.2

Expansion Busses

PCI Express x 16 Gen3 (can be configured to 1x16, 2 x8 or 1 x8 with 2 x4)
6 PCI Express x1 Gen3 (AB): Lanes 0/1/2/3/4/5
2 PCI Express x1 Gen3 (CD): Lane 6/7
Note: PCIe lanes 0/1/2/3 can also be configured to x2, x4 PCIe lanes 4/5/6/7 can also be configured to x2, x4.
LPC bus, SMBus (system), I2C (user)
9
Express-SL/SLE
