Orienting the device
1. Run the PoE cable to the desired location of the PoE injector and insert the cable
into the Data & Power Out port on the PoE power injector.
2. Take a racheting socket wrench and device/ smartphone with the Inseego Mobile
App to the FW2010e location.
3. Use the Inseego Mobile App and the positioning bolts on the device elevation
bracket and bottom of the mount to fine tune the horizontal and vertical angle
of the FW2010e for the best signal.
4. Tighten the positioning bolts to 15.0 Nm (11 ft/lb).
5. Use sealing/weatherproofing material to seal any holes drilled in the structure to
run the PoE cable.
