Testing the connection

Checking the LED on the device
The LED is located in the SIM compartment and is visible through the protective shield.
Connecting a device
You can connect any router or device with Ethernet capability and an Internet browser
to the FW2010e. Connect an Ethernet cable from the Data In port on the PoE power
injector to the connecting device.e
Monitoring and managing your FW2010e
You can use multiple options to monitor and manage your 5G Outdoor CPE:
– Inseego Mobile App - Use the same mobile app you used to install your FW2010e to
perform basic device monitoring and management.
– FW2010e Admin Web UI - Access the Web UI at http://192.168.1.1 for a full set of
device management features. The initial sign in password is: "Fast5G! ".
– Inseego Connect - Go to connect.inseego.com to sign up for a free Inseego
Connect account, which lets you configure the settings, monitor status, and update
the firmware on your device. Additional functionality can be obtained with a
subscription to Inseego Connect Standard or Advanced.
LED Color Operation
Blue Solid
Blinking
Green Solid
Blinking
Yellow Solid
Red Solid
Blinking
Meaning
Strong 5G connection (3 – 5 bars)
Weak 5G connection (1 – 2 bars)
Strong 4G connection (3 – 5 bars)
Weak 4G connection (1 – 2 bars)
Software update is in progress
Router is booting up
No service, SIM error, or locked SIM card
