Attaching the FW2010e to the device elevation bracket
1. Remove the installation handle and unplug the PoE cable from the PoE injector.
2. Attach a ground wire to the back of the device with the ground screw.
3. Place the M6 external locking washers on the M6 21mm bracket mount bolts.
M6 21mm bracket
mount bolt and washer
4. Mount the device to the device elevation bracket using a hex driver to tighten the
bolts to 2.0 Nm (1.48 ft/lb).
M5 10mm ground
screw / washer
7
