When no barcode is recognized, the device will output the content you set here.
Note
The default content is NoRead.
Tcp Output Start Text
The contents of the start part of the data outputted. You can set the contents according to
actual condition.
Tcp Output Stop Text
The contents of the end part of the data outputted. You can set the contents according to actual
condition.
Tcp Output TcpDelimiter
It refers to the delimiter that separates barcode name, position, angle, package ID, etc. You can
set it according to actual condition.
Serial Data Processing
When the communication protocol is Serial, you need to set following parameters in the Data
Processing.
NoRead Image Index
It sets the specific image that is outputted when no barcode information is read. For example, if
you set this parameter as 5, and the 5th image will be output.
Serial Output Barcode Name Enable
If this parameter is enabled, the outputted barcode information will contain the name of the
barcode.
Serial Output Barcode Position Enable
ID5000 Series Smart Code Reader
Figure 7-38 TCP Client Data Processing
