mode to let the acquisition of image data occur only when the trigger source is generated.

7.5.1 Set Trigger Mode

The camera has 2 types of trigger modes, including internal trigger mode and external trigger
mode.
Internal Trigger Mode
In this mode, the camera acquires images via its internal signals.
External Trigger Mode
In this mode, the camera acquires images via external signals like software signal and hardware
signal. The trigger source of external trigger mode includes Software, LineIn 0, LineIn 1, LineIn
2, Counter 0, TCP Start, UDP Start, and Serial Start.

7.5.2 Enable Internal Trigger Mode

You can click I/O Control Settings → Input → Trigger Mode, and select Off as Trigger Mode.
In this mode, the camera acquires images via its internal signals, and you do not need to set any
parameters.
Note
Off refers to the internal trigger mode.

7.5.3 Enable External Trigger Mode

You can click I/O Control Settings → Input → Trigger Mode, and select On as Trigger Mode.
In this mode, the camera acquires images via external signals like software signal and hardware
signal. You can select different trigger sources, set trigger delay time, etc.
Note
On refers to the external trigger mode.
Set and Execute Software Trigger Mode
In software trigger, the software sends trigger signal to the camera via I/O interface to acquire
images.
Steps
1. Click I/O Control Settings → Input → Trigger Mode.
2. Select On as Trigger Mode.
3. Select Software as Trigger Source.
4. Click Execute in Trigger Source to send trigger commands.
