7.3.2 Set Light Source

You can select different light types, and set their related parameters in light interface.
Note
● For different models of camera, the light source parameters may be different, and the actual
product you purchased shall prevail.
● Make sure you have select the camera to be set in Device Connection before setting light
parameters.
You can select different light sources in Light Type.
Own Lighting
It refers to use the device's embedded light source to light during code reading.
External Lighting
It refers to the device controls the external light source by triggering output signal during code
reading.
Non-Lighting
It refers to the device turns off light source during code reading.
Note
If you select Non-Lighting as Light Type, you do not need to set any parameters.
If you select Own Lighting as Light Type, you can set the following parameters.
Light Mode
It has 2 light modes, including Flash Strobe and Strobe Long. Flash Strobe means the light
flashes at a specific interval during code reading, and Strobe Long means the light is solid during
code reading.
Lighting Duration
It sets the lighting duration and the unit is μs.
ID5000 Series Smart Code Reader
Figure 7-2 Set Image
