4.1 Installation Preparation
You need to prepare following accessories before installation.
No.
1
Power and I/O Cable
2
Network Cable
DC Switch Power
3
Supply
4
Fixed Bracket
4.2 Install Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure all the related equipment is power-off during the installation.
Steps
1. Use M4 screw to fix the device to fixed bracket.
2. Select one of installation methods, and install the device to the installation position.
ID5000 Series Smart Code Reader
Chapter 4 Installation
Table 4-1 Accessories
Name
Quantity
1
1
1
1
It refers to the 12-pin power and I/O cable.
It refers to the GigE network cable with RJ45
aviation connector.
It refers to DC switch power supply of 24 VDC
and above 1A/2A. You need to purchase
separately.
It is used to fix the device. You need to
purchase separately.
10
Description
