12.2

Controls

Use the following rules to operate the NetGuardian's control:
1. Select Controls from the Monitor menu.
2. Under the State field, you can see the current condition of the control.
3. To issue the control, click on a command (OPR - operate, RLS - release, or MOM - momentary)
ID
Description
State
Command
2) The maximum time value is 18 hours. Once 18 hours is reached, the timer will
stop counting.
3) The timer will survive a soft reboot (a reboot from the web interface).
4) The timer will not survive a hard reboot (losing power, disconnection, etc). The
timer will be restored to its previously saved value.
View and operate control relays from the Monitor > Controls menu
Control Relay Operation
ID number for the control relay.
Description for the NetGuardian's control relay defined in the Provisioning > Controls
menu.
Status of the control relay. Can either be Released or Latched.
OPR - Latch the relay.
RLS - Release the relay.
61
