Avnet SMARC MSC SM2S-IMX8MINI User Manual page 24

Primary (Top) Side
P35 SDIO_CD#
P36 SDIO_CK
P37 SDIO_PWR_EN
P38 GND
P39 SDIO_D0
P40 SDIO_D1
P41 SDIO_D2
P42 SDIO_D3
P43 SPI0_CS0#
P44 SPI0_CK
P45 SPI0_DIN
P46 SPI0_DO
P47 GND
P48 NC
P49 NC
P50 GND
P51 NC
P52 NC
P53 GND
P54 SPI1_CS0#
P55 SPI1_CS1#
MSC SM2S-IMX8MINI
User Manual
Secondary (Bottom) Side
S35 USB4+
S36 USB4-
S37 NC
S38 AUDIO_MCK
S39 I2S0_LRCK
S40 I2S0_SDOUT
S41 I2S0_SDIN
S42 I2S0_CK
S43 NC
S44 NC
S45 NC
S46 NC
S47 GND
S48 I2C_GP_CK
S49 I2C_GP_DAT
S50 I2S2_LRCK
S51 I2S2_SDOUT
S52 I2S2_SDIN
S53 I2S2_CK
S54 NC
S55 NC
Primary (Top) Side
P56 SPI1_CK
P57 SPI1_DIN
P58 SPI1_DO
P59 GND
P60 USB0+
P61 USB0-
P62 USB0_EN_OC#
P63 USB0_VBUS_DET
P64 USB0_OTG_ID
P65 USB1+
P66 USB1-
P67 USB1_EN_OC#
P68 GND
P69 USB2+
P70 USB2-
P71 USB2_EN_OC#
P72 NC
P73 NC
P74 USB3_EN_OC#
KEY
Secondary (Bottom) Side
S56 NC
S57 NC
S58 NC
S59 NC
S60 NC
S61 GND
S62 NC
S63 NC
S64 GND
S65 NC
S66 NC
S67 GND
S68 USB3+
S69 USB3-
S70 GND
S71 NC
S72 NC
S73 GND
S74 NC
S75 NC
KEY
24 / 87
