Avnet SMARC MSC SM2S-IMX8MINI User Manual page 76

7.3.2.3 Booting OS from Network (Ethernet)
BOOT_SEL0#
HIGH
In this configuration the Linux kernel image (Image) and the device tree blob are loaded from the TFTP-, and the Linux file system is mounting on NFS-
Server on LAN.
Depending on your local network infrastructure, set the following environment variables at the U-Boot prompt:
setenv serverip <TFTP/NFS server IP>
setenv nfsroot <nfs root path on NFS server>
saveenv
Example:
Then continue system boot with:
Boot
or simply reboot (power cycle) your system.
MSC SM2S-IMX8MINI
User Manual
Network Boot Mode
BOOT_SEL1# BOOT_SEL2#
LOW HIGH
Table 29: Network Boot Mode
Figure 7-22. Preparing U-Boot environment for net boot.
Dip Switches on SM2-MB-EP1
76 / 87
