1.4.2 Hardware used

Order
Reference
Number
78402 MSC SM2S-IMX8MINIQC-14N0261I PCBFTX
78370 MSC SM2S-IMX8MINIQC-13N4200I PCBFTX
79649 MSC SM2S-IMX8MINIQC-03N0840E PCBFTX
78368 MSC SM2S-IMX8MINIDC-03N4200I PCBFTX
78404 MSC SM2S-IMX8MINISC-03N4210I PCBFTX
78406 MSC SM2S-IMX8MINISCL-03N0880I PCBFTX

1.4.3 Measurement Results

Order
Reference
Number
78402 MSC SM2S-IMX8MINIQC-14N0261I PCBFTX
78370 MSC SM2S-IMX8MINIQC-13N4200I PCBFTX
79649 MSC SM2S-IMX8MINIQC-03N0840E PCBFTX
78368 MSC SM2S-IMX8MINIDC-03N4200I PCBFTX
78404 MSC SM2S-IMX8MINISC-03N4210I PCBFTX
78406 MSC SM2S-IMX8MINISCL-03N0880I PCBFTX
*
NOTE: Unless stated otherwise, all measurements were taken at room temperature approx 23°C.
MSC SM2S-IMX8MINI
User Manual
Table 2: Modules used for Power Consumption Measurement
CPU
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
i.MX8M Mini Quad, Quad-Core Cortex-A53 at 1.8GHz
i.MX8M Mini Dual, Dual-Core Cortex-A53 at 1.8GHz
i.MX8M Mini Solo, Single-Core Cortex-A53 at 1.8GHz
i.MX8M Mini Solo Lite, Single-Core Cortex-A53 at 1.8GHz
Table 3: Typical Power Consumption Measurement
Uboot Idle [W] Linux idle [W]
2.045 1.790
2.030 1.780
1.950 1.710
1.905 1.615
1.810 1.580
1.925 1.660
RAM
2G LPDDR4
2G LPDDR4
1G LPDDR4
1G LPDDR4
1G LPDDR4
1G LPDDR4
*
Linux Heavy
Deep Sleep [W]
Load [W]
4.650 0.315
4.610 0.315
4.320 0.140
3.820 0.350
3.050 0.310
3.046 0.140
Temp. Range
-40°C to +85°C
-40°C to +85°C
-25°C to +85°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
