Diagnostic information

9 Diagnostic information
Faults detected by the self-monitoring system of the measuring device are displayed as a
diagnostic message in alternation with the operational display. The message about remedial
measures can be called up from the diagnostic message, and contains important information
on the fault.
X X X X X X X X
X
 22 Message about remedial measures
1 Diagnostic information
2 Short text
3 Service ID
4 Diagnostic behavior with diagnostic code
5 Operation time of occurrence
6 Remedial measures
1. The user is in the diagnostic message.
Press  ( symbol).
 The Diagnostic list submenu opens.
2. Select the desired diagnostic event with  or  and press  .
 The message about the remedial measures opens.
3. Press  +  simultaneously.
 The message about the remedial measures closes.
52
S
X
20.50
XX
X X X X X X X X
S801
Supply voltage
1.
Diagnostic list
Diagnostics 1
1
S801 Supply voltage
Diagnostics 2
Diagnostics 3
2.
Supply voltage
2
S801 0d00h02m25s
4
Increase supply voltage
6
3.
Flowmeter Proline 400
S
X
i Menu
S
(ID:203)
Endress+Hauser
3
5
A0029431-EN
