6.3

Access to the operating menu via the Web browser

6.3.1 Function scope
Thanks to the integrated Web server, the device can be operated and configured via a Web
browser and via a service interface (CDI-RJ45) or via a WLAN interface. The structure of the
operating menu is the same as for the local display. In addition to the measured values, device
status information is also displayed, allowing users to monitor the status of the device.
Furthermore the device data can be managed and the network parameters can be configured.
A device that has a WLAN interface (can be ordered optionally) is required for the WLAN
connection: order code for "Display", option BA "WLAN". The device acts as an Access Point and
enables communication by computer or a mobile handheld terminal.
For additional information on the Web server, refer to the Special Documentation for the
device
6.3.2 Prerequisites
Computer hardware
Hardware
Interface
Connection
Screen
Computer software
Software
Recommended operating systems
Web browsers supported
Endress+Hauser
Interface
CDI-RJ45
The computer must have an RJ45
interface.
Standard Ethernet cable with RJ45
connector.
Recommended size: ≥12" (depends on the screen resolution)
Interface
CDI-RJ45
• Microsoft Windows 8 or higher.
• Mobile operating systems:
• iOS
• Android

Microsoft Windows XP is supported.

Microsoft Windows 7 is supported.
• Microsoft Internet Explorer 8 or higher
• Microsoft Edge
• Mozilla Firefox
• Google Chrome
• Safari
Operation options
WLAN
The operating unit must have a
WLAN interface.
Connection via Wireless LAN.
WLAN
