Endress+Hauser HART Flowmeter Proline 400 Brief Operating Instructions page 22

Transmitter with electromagnetic sensor
Table of Contents

Advertisement

Electrical connection
Transmitter
Electrode cable
17 (0.67)
8 (0.31)
1
2
1
2
1
2
2
 1
Engineering unit mm (in)
A = Termination of the cables
B = Termination of the fine-wire cores with ferrules
1 = Red ferrules,  1.0 mm (0.04 in)
2 = White ferrules,  0.5 mm (0.02 in)
* = Stripping only for reinforced cables
22
100 (3.94)*
80 (3.15)
50 (1.97)
A
B
GND
Coil current cable
8 (0.31)
1
 2
A0032093
Flowmeter Proline 400
90
(3.54)
*
70 (2.76)
50 (1.97)
10 (0.39)
A
B
Engineering unit mm (in)
Endress+Hauser
A0032096
