Flowmeter Proline 400
4. Strip the cable and cable ends. In the case of stranded cables, also fit ferrules.
5. Connect the cables according to the connection nameplate on the main electronics
module, for supply voltage: open the shock protection cover.
6. Firmly tighten the cable glands.
Reassembling the transmitter
1. Close the shock protection cover.
2. Close the housing cover.
3.
WARNING
L
Housing degree of protection may be voided due to insufficient sealing of the
housing.
‣
Screw in the screw without using any lubricant.
Tighten the 4 fixing screws on the housing cover.
Endress+Hauser
Electrical connection
