Flowmeter Proline 400
Function row
Functions Meaning
Measured values Displays the measured values of the device
• Access to the operating menu from the measuring device
• The structure of the operating menu is the same as for the local display
Menu

Device status Displays the diagnostic messages currently pending, listed in order of priority
Data exchange between PC and measuring device:
• Device configuration:
Data management
• Logbook - Export Event logbook (.csv file)
• Documents - Export documents:
Configuration and checking of all the parameters required for establishing the connection to the
Network measuring device:
configuration • Network settings (e.g. IP address, MAC address)
• Device information (e.g. serial number, firmware version)
Logout End the operation and call up the login page
Navigation area
If a function is selected in the function bar, the submenus of the function open in the
navigation area. The user can now navigate through the menu structure.
Working area
Depending on the selected function and the related submenus, various actions can be
performed in this area:
• Configuring parameters
• Reading measured values
• Calling up help text
• Starting an upload/download
6.3.6 Disabling the Web server
The Web server of the measuring device can be switched on and off as required using the
Web server functionality parameter.
Navigation
"Expert" menu → Communication → Web server
Endress+Hauser
For detailed information on the structure of the operating menu, see the Operating
Instructions for the measuring device
• Load settings from the device
(XML format, save configuration)
• Save settings to the device
(XML format, restore configuration)
• Export backup data record
(.csv file, create documentation of the measuring point configuration)
• Verification report
(PDF file, only available with the "Heartbeat Verification" application package)
Operation options
