MODEL: 2013 RZR 4 / EPS 800
MODEL NUMBER: R13XE76AD
MODEL NUMBER: R13XE7EAI; Z14XE7EAL
Engine
Platform Cylinder, Liquid Cooled, 4-
Engine Number
Engine Displacement
Number of Cylinders
Bore & Stroke (mm)
Compression Ratio
Compression Pressure
Engine Idle Speed
Engine Max Operating
RPM
Lubrication
Oil Requirements
Oil Capacity
Coolant Capacity
Overheat Warning
Exhaust System
Fuel System
Fuel System Type
Fuel Delivery
2013: 45 +/- 2 psi (310 +/-
Fuel Pressure
2014: 58 +/- 2 psi (400 +/-
Fuel Filters
Fuel Capacity /
Requirement
Electrical
Alternator Rated Output
Headlights (Halogen)
Headlights (LED)
H.O. Domestic Twin
Stroke
1204671 RZR800-13
760cc H.O.
2
80 x 76.5 mm
11:1
165 - 185 psi
1250 ± 100 RPM
6750 RPM
Pressurized Wet Sump
PS-4 Synthetic
2 qts. / 1.9 liters
5.5 qts. / 5.2 liters
Instrument Cluster
Indicator
Dual Headpipe / Single
Silencer
Bosch M17 EFI
Electronic Fuel Pump (in
tank)
14 kPa)
14 kPa)
See Chapter 4
7.25 gal. (27.4 liters)
87 Octane (minimum)
500 Watts @ 3000 RPM
2 - Halogen: Low 55 W /
High 60 W
2 - Dual Beam LED:
9924882 - 2013–2014 RZR 800
© Copyright 2013 Polaris Sales Inc.
GENERAL INFORMATION
Engine
Tail / Brake 2 - 6 Watts / 2 - 27 Watts
Starting System
Ignition System
Ignition Timing
(Variable)
RC7YC3 / 0.035 in. (0.9
Spark plug / Gap
Battery
Multifunction Instrument
Instrument Type
DC Outlets
Relays
Circuit Breaker
Drive / Fuel Pump: 10 Amp
Fuses (Fuse/Relay Box) Lights / EFI / Accessory: 20
Fuses (Power Fuse
Holder) Chassis / EPS: 30 Amp
Drivetrain
Transmission Type
Drive Ratio - Front
Drive Ratio - Final
In Line Shift - H / L / N / R
Shift Type
Front Gearcase
Fluid Type / Capacity
Transmission: Main
Gearcase
Fluid Type / Capacity
Transmission: Transfer
Case
Fluid Type / Capacity
Rear Gearcase
Fluid Type / Capacity
Clutch Type
Drive Belt
1
Low 27 Watts; High 40
Watts
Electric Start
Bosch M17 (ECU
Controlled)
3° - 10° BTDC @ 1200
RPM
mm)
Deka ETX30L / 30 AH
365 CCA / 12 Volt
Cluster
(2) Standard 12 Volt
Chassis / EFI / Fan
Fuel Pump / EPS
Fan Motor: 20 Amp
Amp
EFI: 20 Amp
Polaris Automatic PVT
3.82:1
3.70:1
/ P
Polaris Demand Drive
6.75 oz. (200 ml)
Polaris AGL
24 oz. (710 ml)
Polaris AGL
14 oz. (414 ml)
Polaris Premium ADF
26 oz. (769 ml)
Standard PVT
3211133
1.13
