Disassembly and Reassembly
6. Remove the seven screws securing the OPE PBA
8. Remove the Key Pad from the OPE Cover.
and remove it.
OPE PBA
Key Pad
7. Remove the Contact Rubber from the OPE Cover.
Contact Rubber
3-5
Service Manual
