Page 1 F-114 / F-114P SERVICE MANUAL ifications & F...
Page 3 ifications...
Page 7 Precautions 1. Precautions 1.1 Safety Warning authorized Warning >> Never operate or service the printer with the protective cover removed from Laser/Scanner assembly. The reflected beam, although invisible, can damage your eyes. When using this product, these basic safety pre-cautions should always be followed to reduce risk of fire, electric shock, and injury to persons. Service Manual...
Page 8 Precautions 1.2 Caution for safety 1.2.1 Toxic material 1.2.2 Electric Shock and Fire Safety Precautions It is Service Manual...
Page 9 Precautions 1.2.3 Handling Precautions 1.2.4 Assembly / Disassembly Precautions authorized Service Manual...
Page 10 Precautions 1.2.5 Disregarding this warning may cause bodily injury (1) Be careful with the high temperature part. (2) Do not put finger or hair into the rotating parts. (3) When you move the printer. (4) Ensure the printer is installed safely. Service Manual...
Page 11 Precautions 1.3 ESD Precautions Caution >>Be sure no power is applied to the chassis or circuit, and observe all other safety precautions. Service Manual...
Page 13 Product spec and feature F-114 Series F-114P F-114 Service Manual...
Page 14 Product spec and feature F-114 F-114P F-114 Service Manual...
Page 15 Product spec and feature 114P Service Manual...
Page 16 Product spec and feature F-114P F-114 Service Manual...
Page 17 Summary of Product Product spec and feature Service Manual...
Page 18 Product spec and feature 114P F-114 Service Manual...
Page 19 Product spec and feature 114 / F-114P Service Manual...
Page 20 Product spec and feature Service Manual...
Page 21 Product spec and feature 114 / F-114P 114 / F-114P 114P Service Manual...
Page 22 Product spec and feature 2-10 Service Manual...
Page 23 Product spec and feature 2-11 Service Manual...
Page 24 Product spec and feature 2-12 Service Manual...
Page 25 Product spec and feature 2-13 Service Manual...
Page 26 Product spec and feature 2-14 Service Manual...
Page 27 Product spec and feature 2-15 Service Manual...
Page 28 Product spec and feature The unt' 2-16 Service Manual...
Page 29 Product spec and feature 2-17 Service Manual...
Page 30 Product spec and feature 2-18 Service Manual...
Page 31 Product spec and feature 2-19 Service Manual...
Page 32 Product spec and feature 2-20 Service Manual...
Page 33 Product spec and feature 2-21 Service Manual...
Page 34 Product spec and feature 2-22 Service Manual...
Page 35 Product spec and feature 2-23 Service Manual...
Page 37 Service Manual...
Page 38 Note: Check the roller for any dirt. Clean with a soft cloth dampened with water. If the roller is heavily worn replace it with a new one. Service Manual...
Page 39 Service Manual...
Page 40 Service Manual...
Page 41 Service Manual...
Page 42 Note: • When you reassemble the Rubber Pad, be sure that the Rubber Pad and Holder fit into the Guide Boss and the Holder latches fit into the corresponding holes. Then push firmly until it clicks. • Clean the surface of the Rubber Pad with ethyl alcohol. After wiping it, be sure to dry it.
Page 43 Service Manual...
Page 44 Service Manual...
Page 45 Service Manual...
Page 46 3-10 Service Manual...
Page 47 3-11 Service Manual...
Page 48 3-12 Service Manual...
Page 49 Note : When re-fitting the Drive Ass’y tighten the screws in the order that they are numbered on the base plate. 3-13 Service Manual...
Page 50 3-14 Service Manual...
Page 51 3-15 Service Manual...
Page 52 3-16 Service Manual...
Page 53 3-17 Service Manual...
Page 54 3-18 Service Manual...
Page 55 3-19 Service Manual...
Page 56 3-20 Service Manual...
Page 57 3-21 Service Manual...
Page 58 3-22 Service Manual...
Page 59 3-23 Service Manual...
Page 61 ADF R L S U Fuser Toner Cartridge Service Manual...
Page 62 ADF R Service Manual...
Page 63 L S U Fuser Toner Cartridge Service Manual...
Page 64 L S U L S U Fuser Toner Cartridge Fuser Toner Cartridge L S U L S U Fuser Toner Cartridge Fuser Toner Cartridge Service Manual...
Page 65 NOTE :To prevent document jams do not use thick, thin or mixed documents. Service Manual...
Page 66 Service Manual...
Page 67 Service Manual...
Page 68 Service Manual...
Page 69 Service Manual...
Page 70 NOTE :The fuser area is hot. Take care when removing paper from the machine. Service Manual...
Page 71 Service Manual...
Page 72 Service Manual...
Page 73 Service Manual...
Page 74 Caution : The Send Fax Level is set to the best condition during manufacture. Never change settings arbitrarily. NOTICE : Always perform a memory clear after replacing the main board, otherwise the system may not operate properly. Service Manual...
Page 75 Service Manual...
Page 76 NOTICE : When you test the CIS, make sure that the cover is closed. Service Manual...
Page 77 Service Manual...
Page 78 Service Manual...
Page 79 Service Manual...
Page 80 Service Manual...
Page 81 L S U Fuser Toner Cartridge Service Manual...
Page 82 Service Manual...
Page 83 Service Manual...
Page 84 Service Manual...
Page 85 Adjustment and Troubleshooting Service Manual 4-25...
Page 86 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-26...
Page 87 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-27...
Page 88 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-28...
Page 89 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-29...
Page 90 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-30...
Page 91 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-31...
Page 92 Adjustment and Troubleshooting Service Manual 4-32...
Page 93 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-33...
Page 94 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-34...
Page 95 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-35...
Page 96 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-36...
Page 97 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-37...
Page 98 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-38...
Page 99 Adjustment and Troubleshooting Digital Digital Pri Digital Printer Digital Printer Digital Printer Service Manual 4-39...
Page 100 Adjustment and Troubleshooting Service Manual 4-40...
Page 101 Adjustment and Troubleshooting Service Manual 4-41...
Page 102 Adjustment and Troubleshooting Service Manual 4-42...
Page 103 Adjustment and Troubleshooting Service Manual 4-43...
Page 104 Adjustment and Troubleshooting Service Manual 4-44...
Page 105 Adjustment and Troubleshooting Service Manual 4-45...
Page 106 Adjustment and Troubleshooting Service Manual 4-46...
Page 107 Adjustment and Troubleshooting Service Manual 4-47...
Page 108 Adjustment and Troubleshooting Service Manual 4-48...
Page 109 Adjustment and Troubleshooting Service Manual 4-49...
Page 110 Adjustment and Troubleshooting Service Manual 4-50...
Page 111 Adjustment and Troubleshooting Service Manual 4-51...
Page 112 Adjustment and Troubleshooting Service Manual 4-52...
Page 113 Adjustment and Troubleshooting Service Manual 4-53...
Page 114 Adjustment and Troubleshooting Service Manual 4-54...
Page 115 Adjustment and Troubleshooting Service Manual 4-55...
Page 116 Adjustment and Troubleshooting Service Manual 4-56...
Page 117 Adjustment and Troubleshooting L S U Fuser Toner Cartridge EXIT Sensor MP Sensor Feed Sensor Empty Sensor Service Manual 4-57...
Page 118 Adjustment and Troubleshooting L S U Fuser Toner Cartridge EXIT Sensor MP Sensor Feed Sensor Empty Sensor Service Manual 4-58...
Page 119 Adjustment and Troubleshooting L S U Fuser Toner Cartridge EXIT Sensor MP Sensor Feed Sensor Empty Sensor Service Manual 4-59...
Page 120 Adjustment and Troubleshooting Service Manual 4-60...
Page 121 Adjustment and Troubleshooting Service Manual 4-61...
Page 122 Adjustment and Troubleshooting Service Manual 4-62...
Page 123 Adjustment and Troubleshooting Service Manual 4-63...
Page 124 Adjustment and Troubleshooting Service Manual 4-64...
Page 125 Adjustment and Troubleshooting Service Manual 4-65...
Page 126 Adjustment and Troubleshooting Service Manual 4-66...
Page 127 Adjustment and Troubleshooting Service Manual 4-67...
Page 128 Adjustment and Troubleshooting Service Manual 4-68...
Page 129 Adjustment and Troubleshooting Service Manual 4-69...
Page 130 Adjustment and Troubleshooting Service Manual 4-70...
Page 131 Adjustment and Troubleshooting Service Manual 4-71...
Page 132 Adjustment and Troubleshooting Service Manual 4-72...
Page 133 Adjustment and Troubleshooting authorized Note : Help the environment by recycling your used toner car- tridge. Refer to the recycling brochure packed with the toner cartridge for details. Service Manual 4-73...
Page 134 Adjustment and Troubleshooting Service Manual 4-74...
Page 135 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-75...
Page 136 Adjustment and Troubleshooting Digital Printer Digital Printer Digital Printer Digital Printer Digital Printer Service Manual 4-76...
Page 137 Adjustment and Troubleshooting Service Manual 4-77...
Page 138 Adjustment and Troubleshooting Service Manual 4-78...
Page 139 Adjustment and Troubleshooting Service Manual 4-79...
Page 140 Adjustment and Troubleshooting Service Manual 4-80...
Page 141 Adjustment and Troubleshooting Service Manual 4-81...
Page 143 Exploded View and Parts list Service Manual...
Page 144 Exploded View and Parts List Service Manual...
Page 145 Exploded View and Parts List Service Manual...
Page 146 Exploded View and Parts List Service Manual...
Page 147 Exploded View and Parts List Service Manual...
Page 148 Exploded View and Parts List 5-11 Service Manual...
Page 149 Exploded View and Parts List 5-14 Service Manual...
Page 150 Exploded View and Parts List 5-16 Service Manual...
Page 151 Exploded View and Parts List 5-18 Service Manual...
Page 153 System Diagram Service Manual...
Page 154 System Diagram Service Manual...
Page 155 Reference Information Service Manual...
Page 156 Reference Information Service Manual...
Page 157 Reference Information Service Manual...
Page 158 Reference Information Service Manual...
Page 159 Reference Information Service Manual...
