• VESA and OpenLDI LVDS color mappings

• automatic panel detection via Embedded Panel Interface based on VESA EDID

• resolution up to 1920x1200 in dual LVDS channel mode

The eDP

1,2

interface supports:

• eDP 1.3 specification

• Spread-Spectrum Clocking

• eDP display authentication

Note

The conga-TCV2 supports either LVDS (default) or eDP (assembly option).

The eDP interface does not support HDCP

5.1.4

SATA

The conga-TCV2 offers two SATA ports. The first SATA port can be routed to SATA port 0 or SATA port 2 on the COM Express connector. The

second SATA port can be routed to SATA port 1 or SATA port 3 on the COM Express connector. To set the active COM Express SATA ports,

use the BIOS setup menu.

The SATA interfaces support:

• data transfer rates up to 6.0 Gb/s

• AHCI mode Hot-plug detect

Note

The interfaces do not support legacy mode using I/O space.

1.3

TCV2m01

26/65
