Table 15 PCI Express Signal Descriptions (x16 Graphics)
Signal Pin # Description
PEG_RX0+ C52 PCI Express Graphics differential pairs 0
Note: Can also be used as PCI Express differential pairs 16
PEG_RX0- C53
PEG_TX0+ D52
PEG_TX0- D53
PEG_RX1+ C55 PCI Express Graphics differential pairs 1
PEG_RX1- C56 Note: Can also be used as PCI Express differential pairs 17
PEG_TX1+ D55
PEG_TX1- D56
PEG_RX2+ C58 PCI Express Graphics differential pairs 2
Note: Can also be used as PCI Express differential pairs 18
PEG_RX2- C59
PEG_TX2+ D58
PEG_TX2- D59
PEG_RX3+ C61 PCI Express Graphics differential pairs 3
Note: Can also be used as PCI Express differential pairs 19
PEG_RX3- C62
PEG_TX3+ D61
PEG_TX3- D62
PEG_RX4+ C65 PCI Express Graphics differential pairs 4
PEG_RX4- C66 Note: Can also be used as PCI Express differential pairs 20
PEG_TX4+ D65
PEG_TX4- D66
PEG_RX5+ C68 PCI Express Graphics differential pairs 5
Note: Can also be used as PCI Express differential pairs 21
PEG_RX5- C69
PEG_TX5+ D68
PEG_TX5- D69
PEG_RX6+ C71 PCI Express Graphics differential pairs 6
Note: Can also be used as PCI Express differential pairs 22
PEG_RX6- C72
PEG_TX6+ D71
PEG_TX6- D72
PEG_RX7+ C74 PCI Express Graphics differential pairs 7
PEG_RX7- C75 Note: Can also be used as PCI Express differential pairs 23
PEG_TX7+ D74
PEG_TX7- D75
PEG_RX8+ C78 PCI Express Graphics differential pairs 8
Note: Can also be used as PCI Express differential pairs 24
PEG_RX8- C79
PEG_TX8+ D78
PEG_TX8- D79
PEG_RX9+ C81 PCI Express Graphics differential pairs 9
Note: Can also be used as PCI Express differential pairs 25
PEG_RX9- C82
PEG_TX9+ D81
PEG_TX9- D82
Copyright © 2021 congatec GmbH
I/O PU/PD
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
I PCIE
O PCIE
TCV2m01
Comment
PCI Express Gen 3
Not connected
46/65
