Table 35 Module Type Definition Signal Description
Signal Pin # Description
TYPE0# C54 The TYPE pins indicate to the carrier board the pinout type that is implemented on the
TYPE1# C57 module.
TYPE2# D57
The pins are tied on the module to either ground (GND) or are no-connects (NC). For
pinout Type 1, these pins are don't care (X).
TYPE2#
X
NC
NC
NC
NC
GND
The carrier board should implement combinatorial logic that monitors the module 'TYPE'
pins and keeps power off (e.g deactivates the ATX_ON signal for an ATX power supply) if
an incompatible module pin-out type is detected.
The carrier board logic may also implement a fault indicator such as an LED.
TYPE10# A97 Dual use pin.
Indicates to the carrier board that a Type 10 module is installed.
Indicates to the carrier that a Rev. 1.0/2.0 module is installed.
TYPE10#
NC
PD
12V
This pin is reclaimed from VCC_12V pool. In R1.0 modules this pin will connect to other
VCC_12V pins.
In R2.0 this pin is defined as a no-connect for Types 1-6. A carrier can detect a R1.0
module by the presence of 12 V on this pin. R2.0 module Types 1-6 will no-connect this
pin. Type 10 modules shall pull this pin to ground through a 4.7 kΩ resistor.
Copyright © 2021 congatec GmbH
TYPE1# TYPE0#
X X
NC NC
NC GND
GND NC
GND GND
NC NC
Pinout R2.0
Pinout Type 10 pull down to ground with 4.7k
resistor
Pinout R1.0
I/O
PDS
Pinout Type 1
Pinout Type 2
Pinout Type 3 (no IDE)
Pinout Type 4 (no PCI)
Pinout Type 5 (no IDE, no PCI)
Pinout Type 6 (no IDE, no PCI)
PDS
TCV2m01
Comment
TYPE[0:2]# signals are available on
all modules following the Type 2-6
Pinout standard.
The conga-TCV2 is based on the
COM Express Type 6 pinout therefore
the pins 0 and 1 are not connected
and pin 2 is connected to GND.
Not connected to indicate "Pinout
R2.0".
