8.1

A-B Connector Signal Descriptions

Table 12 Connector A–B Pinout
Pin Row A
A1 GND (FIXED)
A2 GBE0_MDI3-
A3 GBE0_MDI3+
A4 GBE0_LINK100#
A5 GBE0_LINK1000#
A6 GBE0_MDI2-
A7 GBE0_MDI2+
A8 GBE0_LINK#
A9 GBE0_MDI1-
A10 GBE0_MDI1+
A11 GND (FIXED)
A12 GBE0_MDI0-
A13 GBE0_MDI0+
A14 GBE0_CTREF
1
A15 SUS_S3#
A16 SATA0_TX+
A17 SATA0_TX-
A18 SUS_S4#
A19 SATA0_RX+
A20 SATA0_RX-
A21 GND (FIXED)
A22 SATA2_TX+
A23 SATA2_TX-
A24 SUS_S5#
A25 SATA2_RX+
A26 SATA2_RX-
A27 BATLOW#
A28 (S)ATA_ACT#
A29 HDA_SYNC
A30 HDA_RST#
Copyright © 2021 congatec GmbH
Pin Row B
B1 GND (FIXED)
B2 GBE0_ACT#
B3 LPC_FRAME#
B4 LPC_AD0
B5 LPC_AD1
B6 LPC_AD2
B7 LPC_AD3
B8 LPC_DRQ0#
B9 LPC_DRQ1#
1
B10 LPC_CLK
B11 GND (FIXED)
B12 PWRBTN#
B13 SMB_CK
B14 SMB_DAT
B15 SMB_ALERT#
B16 SATA1_TX+
B17 SATA1_TX-
B18 SUS_STAT#
B19 SATA1_RX+
B20 SATA1_RX-
B21 GND (FIXED)
B22 SATA3_TX+
B23 SATA3_TX-
B24 PWR_OK
B25 SATA3_RX+
B26 SATA3_RX-
B27 WDT
B28 HDA_SDIN2
B29 HDA_SDIN1
B30 HDA_SDIN0
Pin Row A
A56 PCIE_TX4-
A57 GND
A58 PCIE_TX3+
A59 PCIE_TX3-
A60 GND (FIXED)
A61 PCIE_TX2+
A62 PCIE_TX2-
A63 GPI1
A64 PCIE_TX1+
A65 PCIE_TX1-
A66 GND
A67 GPI2
A68 PCIE_TX0+
A69 PCIE_TX0-
A70 GND (FIXED)
A71 eDP_TX2+ / LVDS_A0+
A72 eDP_TX2- / LVDS_A0-
A73 eDP_TX1+ / LVDS_A1+
A74 eDP_TX1- / LVDS_A1-
A75 eDP_TX0+ / LVDS_A2+
A76 eDP_TX0- / LVDS_A2-
A77 eDP_VDD_EN/LVDS_VDD_EN
A78 LVDS_A3+
A79 LVDS_A3-
A80 GND (FIXED)
A81 eDP_TX3+ / LVDS_A_CK+
A82 eDP_TX3- / LVDS_A_CK-
A83 eDP_ AUX+ / LVDS_I2C_CK
A84 eDP_AUX- / LVDS_I2C_DAT
A85 GPI3
TCV2m01
Pin Row B
B56 PCIE_RX4-
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND (FIXED)
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67 WAKE1#
B68 PCIE_RX0+
B69 PCIE_RX0-
B70 GND (FIXED)
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
B79 eDP_BKLT_EN/LVDS_BKLT_EN
B80 GND (FIXED)
B81 LVDS_B_CK+
B82 LVDS_B_CK-
B83 eDP/LVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
