Congatec COM Express conga-TCV2 User Manual page 44

Pin Row C Pin
C33 DDI2_CTRLDATA_AUX- D33
C34 DDI2_DDC_AUX_SEL D34
C35 RSVD 1 D35
C36 DDI3_CTRLCLK_AUX+ D36
C37 DDI3_CTRLDATA_AUX- D37
C38 DDI3_DDC_AUX_SEL D38
C39 DDI3_PAIR0+ D39
C40 DDI3_PAIR0- D40
C41 GND (FIXED) D41
C42 DDI3_PAIR1+ D42
C43 DDI3_PAIR1- D43
C44 DDI3_HPD D44
C45 RSVD 1 D45
C46 DDI3_PAIR2+ D46
C47 DDI3_PAIR2- D47
C48 RSVD D48
C49 DDI3_PAIR3+ D49
C50 DDI3_PAIR3- D50
C51 GND (FIXED) D51
C52 PEG_RX0+ D52
C53 PEG_RX0- D53
C54 TYPE0# D54
1
C55 PEG_RX1+ D55
Note
1. Not connected
2. Not supported
3. congatec internal use only
Copyright © 2021 congatec GmbH
Row D Pin Row C
DDI1_PAIR2- C88 PEG_RX11+
DDI1_DDC_AUX_SEL C89 PEG_RX11-
RSVD 1 C90 GND (FIXED)
DDI1_PAIR3+ C91 PEG_RX12+
DDI1_PAIR3- C92 PEG_RX12-
RSVD C93 GND
1
DDI2_PAIR0+ C94 PEG_RX13+
DDI2_PAIR0- C95 PEG_RX13-
GND (FIXED) C96 GND
DDI2_PAIR1+ C97 RVSD
DDI2_PAIR1- C98 PEG_RX14+
DDI2_HPD C99 PEG_RX14-
RSVD 1 C100 GND (FIXED)
DDI2_PAIR2+ C101 PEG_RX15+
DDI2_PAIR2- C102 PEG_RX15-
RSVD C103 GND
1
DDI2_PAIR3+ C104 VCC_12V
DDI2_PAIR3- C105 VCC_12V
GND (FIXED) C106 VCC_12V
PEG_TX0+ C107 VCC_12V
PEG_TX0- C108 VCC_12V
PEG_LANE_RV# C109 VCC_12V
1
PEG_TX1+ C110 GND (FIXED)
Pin Row D
D88 PEG_TX11+
1
D89 PEG_TX11-
1
D90 GND (FIXED)
D91 PEG_TX12+
1
1 D92 PEG_TX12-
D93 GND
D94 PEG_TX13+
1
1 D95 PEG_TX13-
D96 GND
1 D97 RSVD 1
D98 PEG_TX14+
1
D99 PEG_TX14-
1
D100 GND (FIXED)
D101 PEG_TX15+
1
1 D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND (FIXED)
TCV2m01
1
1
1
1
1
1
1
1
1
1
44/65
