5.1.3

Display Interface

The conga-TCV2 supports:
• three DP++ (dual-mode DP)
• single- or dual-channel LVDS
• four independent displays (3x DP++ and 1x LVDS/eDP)
The table below shows the supported display combinations and resolutions.
Table 9 Display Combinations and Resolution
Display 1 (DDI1)
Interface Max. Resolution Interface Max. Resolution Interface
Option 1 DP++
Option 2 DP++
5.1.3.1

DisplayPort (DP)

The conga-TCV2 supports:
• up to three DP ports
• VESA DisplayPort Standard 1.4
• data rate of 1.62 GT/s, 2.7 GT/s and 5.4 GT/s on 1, 2 or 4 data lanes
• up to 4096x2160 resolutions at 60 Hz
• maximum of three independent DP displays
5.1.3.2

LVDS/eDP

The conga-TCV2 offers an LVDS interface with optional eDP overlay on the A–B connector. The LVDS interface provides LVDS signals by default,
but can optionally support eDP signals (assembly option).
The LVDS 1 interface supports:
• single or dual channel LVDS (color depths of 18 bpp or 24 bpp)
• integrated flat panel interface with clock frequency up to 112 MHz
Copyright © 2021 congatec GmbH
Display 2 (DDI2)
4096x2160 @ 60 Hz DP++ 4096x2160 @ 60 Hz
4096x2160 @ 60 Hz DP++ 4096x2160 @ 60 Hz
Display 3 (DDI2)
Max. Resolution Interface Max. Resolution
DP++ 4096x2160 @ 60 Hz LVDS
DP++ 4096x2160 @ 60 Hz eDP (BOM
option)
TCV2m01
Display 4
1920x1200 @ 60 Hz (dual LVDS mode)
4096x2160 @ 60 Hz
