Table 17 Tmds Signal Descriptions - Congatec COM Express conga-TCV2 User Manual

Signal Pin # Description
DDI3_PAIR1+ C42 Multiplexed with DP3_LANE1+ and TMDS3_DATA1+
DDI3_PAIR1- C43 Multiplexed with DP3_LANE1- and TMDS3_DATA1-
DDI3_PAIR2+ C46 Multiplexed with DP3_LANE2+ and TMDS3_DATA0+
DDI3_PAIR2- C47 Multiplexed with DP3_LANE2- and TMDS3_DATA0-
DDI3_PAIR3+ C49 Multiplexed with DP3_LANE3+ and TMDS3_CLK+
DDI3_PAIR3- C50 Multiplexed with DP3_LANE3- and TMDS3_CLK-
DDI3_HPD C44 Multiplexed with DP3_HPD and HDMI3_HPD
DDI3_CTRLCLK_AUX+ C36 Multiplexed with DP3_AUX+ and HDMI3_CTRLCLK
DP AUX+ function if DDI3_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLCLK if DDI3_DDC_AUX_SEL is pulled high
DDI3_CTRLDATA_AUX- C37 Multiplexed with DP3_AUX- and HDMI3_CTRLDATA
DP AUX- function if DDI3_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLDATA if DDI3_DDC_AUX_SEL is pulled high
DDI3_DDC_AUX_SEL C38 Selects the function of DDI3_CTRLCLK_AUX+ and DDI3_CTRLDATA_AUX-
This pin shall have a 1 M pull-down to logic ground on the module. If this
input is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-
high, the AUX pair contains the CTRLCLK and CTRLDATA signals.
Note
The DDI interfaces support dual-mode DisplayPort. To support TMDS, an external level shifter (PTN3360D) should be implemented on the
user's carrier board.
Table 17 TMDS Signal Descriptions
Signal Pin # Description
TMDS1_CLK + D36 TMDS Clock output differential pair.
TMDS1_CLK - D37 Multiplexed with DDI1_PAIR3+ and DDI1_PAIR3-
TMDS1_DATA0+ D32 TMDS differential pair.
TMDS1_DATA0- D33 Multiplexed with DDI1_PAIR2+ and DDI1_PAIR2-
TMDS1_DATA1+ D29 TMDS differential pair.
TMDS1_DATA1- D30 Multiplexed with DDI1_PAIR1+ and DDI1_PAIR1-
TMDS1_DATA2+ D26 TMDS differential pair.
TMDS1_DATA2- D27 Multiplexed with DDI1_PAIR0+ and DDI1_PAIR0-
HDMI1_HPD C24 TMDS Hot-plug detect. Multiplexed with DDI1_HPD
HDMI1_CTRLCLK D15 TMDS I
HDMI1_CTRLDATA D16 TMDS I
Multiplexed with DDI1_CTRLDATA_AUX-
Copyright © 2021 congatec GmbH
C Control Clock. Multiplexed with DDI1_CTRLCLK_AUX+
2
C Control Data
2
I/O PU/PD
O DP
O DP
O DP
I 3.3 V PD 100 kΩ
I/O DP PD 100 kΩ For TMDS mode, 2.2K to 3.3V pull-up
OD 3.3 V
I/O DP PU 100 kΩ For TMDS mode, 2.2K to 3.3V pull-up
I/OD 3.3 V
I 3.3 V PD 1 MΩ
I/O PU/PD
O DP
O DP
O DP
O DP
I DP PD 100 kΩ
OD 3.3 V PD 100 kΩ 2.2 kΩ to 3.3V pull-up should be implemented
I/OD 3.3 V PU 100 kΩ
3.3 V
TCV2m01
Comment
Should be AC-coupled on the carrier
board.
resistor should be implemented on
the carrier board.
resistor should be implemented on
the carrier board.
Comment
Should be AC-coupled on the carrier board.
on the carrier board.
2.2 kΩ to 3.3V pull-up should be implemented
on the carrier board.
49/65
