1.2

Options Information

The conga-TCV2 is currently available in four variants. The table below shows the different configurations available.
Table 2 conga-TCV2 Variants
Part-No.
Processor
CPU Max Freq.
L2/L3 Shared Cache 4 MB/8 MB
DDR4 Memory
(ECC or Non-ECC)
Graphics Engine
Graphics Freq.
PCIe Ports (Lanes)
USB
SATA (6 Gb/s)
DDI
LVDS/eDP
SoC TDP
Copyright © 2021 congatec GmbH
050500 050501
AMD Ryzen™ Embedded AMD Ryzen™ Embedded
V2748, 2.9 GHz, 8 Core V2546, 3.0 GHz, 6 Core
4.25 GHz 3.95 GHz
3 MB/8 MB
3200 MT/s dual channel 3200 MT/s dual channel
AMD Radeon™ AMD Radeon™
(7 Compute Units) (6 Compute Units)
1.6 GHz 1.5 GHz
5x PCIe Gen 3 Ports 5x PCIe Gen 3 Ports
(8 lanes) (8 lanes)
4x USB 3.1 Gen 2 4x USB 3.1 Gen 2
4x USB 2.0 4x USB 2.0
2x 2x
3x DP++ 3x DP++
Single or dual LVDS Single or dual LVDS
45 W (35 W – 54 W) 45 W (35 W – 54 W)
050502 050503
AMD Ryzen™ Embedded AMD Ryzen™ Embedded
V2718, 1.7 GHz, 8 Core V2516, 2.1 GHz, 6 Core
4.15 GHz 3.95 GHz
4 MB/8 MB 3 MB/8 MB
3200 MT/s dual channel 3200 MT/s dual channel
AMD Radeon™ AMD Radeon™
(7 Compute Units) (6 Compute Units)
1.6 GHz 1.5 GHz
5x PCIe Gen 3 Ports 5x PCIe Gen 3 Ports
(8 lanes) (8 lanes)
4x USB 3.1 Gen 2 4x USB 3.1 Gen 2
4x USB 2.0 4x USB 2.0
2x 2x
3x DP++ 3x DP++
Single or dual LVDS Single or dual LVDS
15 W (10 W – 15 W) 15 W (10 W – 15 W)
