Table 16 DDI Signal Description
Signal Pin # Description
DDI1_PAIR0+ D26 Multiplexed with DP1_LANE0+ and TMDS1_DATA2+
DDI1_PAIR0- D27 Multiplexed with DP1_LANE0- and TMDS1_DATA2-
DDI1_PAIR1+ D29 Multiplexed with DP1_LANE1+ and TMDS1_DATA1+
DDI1_PAIR1- D30 Multiplexed with DP1_LANE1- and TMDS1_DATA1-
DDI1_PAIR2+ D32 Multiplexed with DP1_LANE2+ and TMDS1_DATA0+
DDI1_PAIR2- D33 Multiplexed with DP1_LANE2- and TMDS1_DATA0-
DDI1_PAIR3+ D36 Multiplexed with DP1_LANE3+ and TMDS1_CLK+
DDI1_PAIR3- D37 Multiplexed with DP1_LANE3- and TMDS1_CLK-
DDI1_HPD C24 Multiplexed with DP1_HPD and HDMI1_HPD
DDI1_CTRLCLK_AUX+ D15 Multiplexed with DP1_AUX+ and HMDI1_CTRLCLK
DP AUX+ function if DDI1_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLCLK if DDI1_DDC_AUX_SEL is pulled high
DDI1_CTRLDATA_AUX- D16 Multiplexed with DP1_AUX- and HDMI1_CTRLDATA
DP AUX- function if DDI1_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLDATA if DDI1_DDC_AUX_SEL is pulled high
DDI1_DDC_AUX_SEL D34 Selects the function of DDI1_CTRLCLK_AUX+ and DDI1_CTRLDATA_AUX-
This pin shall have a IM pull-down to logic ground on the module. If this input
is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-high, the
AUX pair contains the CTRLCLK and CTRLDATA signals.
DDI2_PAIR0+ D39 Multiplexed with DP2_LANE0+ and TMDS2_DATA2+
DDI2_PAIR0- D40 Multiplexed with DP2_LANE0- and TMDS2_DATA2-
DDI2_PAIR1+ D42 Multiplexed with DP2_LANE1+ and TMDS2_DATA1+
DDI2_PAIR1- D43 Multiplexed with DP2_LANE1- and TMDS2_DATA1-
DDI2_PAIR2+ D46 Multiplexed with DP2_LANE2+ and TMDS2_DATA0+
DDI2_PAIR2- D47 Multiplexed with DP2_LANE2- and TMDS2_DATA0-
DDI2_PAIR3+ D49 Multiplexed with DP2_LANE3+ and TMDS2_CLK+
DDI2_PAIR3- D50 Multiplexed with DP2_LANE3- and TMDS2_CLK-
DDI2_HPD D44 Multiplexed with DP2_HPD and HDMI2_HPD
DDI2_CTRLCLK_AUX+ C32 Multiplexed with DP2_AUX+ and HDMI2_CTRLCLK
DP AUX+ function if DDI2_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLCLK if DDI2_DDC_AUX_SEL is pulled high
DDI2_CTRLDATA_AUX- C33 Multiplexed with DP2_AUX- and HDMI2_CTRLDATA
DP AUX- function if DDI2_DDC_AUX_SEL is no connect
HDMI/DVI I2C CTRLDATA if DDI2_DDC_AUX_SEL is pulled high
DDI2_DDC_AUX_SEL C34 Selects the function of DDI2_CTRLCLK_AUX+ and DDI2_CTRLDATA_AUX-
This pin shall have a IM pull-down to logic ground on the module. If this input
is floating, the AUX pair is used for the DP AUX+/- signals. If pulled-high, the
AUX pair contains the CTRLCLK and CTRLDATA signals.
DDI3_PAIR0+ C39 Multiplexed with DP3_LANE0+ and TMDS3_DATA2+
DDI3_PAIR0- C40 Multiplexed with DP3_LANE0- and TMDS3_DATA2-
