7
Mechanical Dimensions and
Packaging
This chapter mainly describes mechanical dimensions and packaging specifications of RM500Q-AE and
RM502Q-AE. All dimensions are measured in mm, and the tolerances are ± 0.05 mm unless otherwise
specified.
7.1. Mechanical Dimensions of the Module
Figure 38: Mechanical Dimensions of the Module (Unit: mm)
RM500Q-AE&RM502Q-AE_Hardware_Design
RM500Q-AE&RM502Q-AE Hardware Design
5G Module Series
80 / 86
