Product Concept

2.1. General Description

RM500Q-AE and RM502Q-AE are 5G NR/LTE-FDD/LTE-TDD/WCDMA wireless communication
modules with receive diversity. They provide data connectivity on 5G NR SA and NSA, LTE-FDD,
LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA networks. They are standard M.2 Key-B
WWAN modules. For more details, see PCI Express M.2 Specification Revision 3.0, Version 1.2
RM500Q-AE and RM502Q-AE are industrial-grade modules for industrial and commercial applications
only.
They support embedded operating systems such as Windows, Linux and Android, and also provide
GNSS and voice* functionality to meet specific application demands.
The following table shows the frequency bands and GNSS type of the module.
Table 2: Frequency Bands and GNSS Type of RM500Q-AE&RM502Q-AE Module
Mode RM500Q-AE&RM502Q-AE
5G NR SA n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79
5G NR NSA n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79
B1/B2/B3/B4/B5/B7/B8/B12(B17)/B13/B14/B18/B19/B20/B25/B26/B28/B29/B30/
LTE-FDD
B32/B66/B71
LTE-TDD B34/B38/B39/B40/B41/B42/B43/B48
LAA B46
WCDMA B1/B2/B3/B4/B5/B6/B8/B19
GNSS GPS/GLONASS/QZSS/BeiDou (COMPASS)/Galileo
