Quectel 5G Module Series Hardware Design page 17

Transmitting Power
5G NR Features
LTE Features
UMTS Features
RM500Q-AE&RM502Q-AE_Hardware_Design
⚫
5G NR bands: Class 3 (23 dBm ± 2 dB)
⚫
5G NR n41/n77/n78/n79 bands HPUE: Class 2 (26 dBm +2/-3 dB)
⚫
LTE bands: Class 3 (23 dBm ± 2 dB)
⚫
LTE B38/B40/B41/B42/B43 bands HPUE
⚫
WCDMA bands: Class 3 (24 dBm +1/-3 dB)
⚫
Supports 3GPP Rel-15
⚫
Supported Modulations:
Uplink: π/2-BPSK, QPSK, 16QAM, 64QAM and 256QAM
-
- Downlink: QPSK, 16QAM, 64QAM and 256QAM
⚫
Supported MIMO:
- Uplink: 2 × 2 MIMO
- Downlink: 4 × 4 MIMO on
n78/n79
⚫
Supports SCS 15 kHz
⚫
4)
Supports SA and NSA
⚫
Supports Option 3x, 3a, 3 and Option 2
⚫
Max. transmission data rates
RM500Q-AE
NSA: 2.5 Gbps (DL)/ 650 Mbps (UL)
SA: 2.1 Gbps (DL)/ 450 Mbps (UL)
RM502Q-AE
NSA: 5 Gbps (DL)/ 650 Mbps (UL)
SA: 4.2 Gbps (DL)/ 450 Mbps (UL)
⚫
Supports 3GPP Rel-15
⚫
LTE Category:
RM500Q-AE: DL Cat 16/ UL Cat 18
RM502Q-AE: DL Cat 20/ UL Cat 18
⚫
Supported modulations:
- Uplink: QPSK, 16QAM and 64QAM and 256QAM*
- Downlink: QPSK, 16QAM and 64QAM and 256QAM
⚫
Supports 1.4/3/5/10/15/20 MHz RF bandwidth
⚫
Supports downlink 4 × 4 MIMO on:
B1/B2/B3/B4/B7/B25/B30/B38/B39/B40/B41/B42/B43/B48/B66
⚫
Max. transmission data rates
RM500Q-AE
LTE: 1.0 Gbps (DL)/ 200 Mbps (UL)
RM502Q-AE
LTE: 2.0 Gbps (DL)/ 200 Mbps (UL)
⚫
Supports 3GPP Rel-9 DC-HSDPA, HSPA +, HSDPA, HSUPA and WCDMA
⚫
Supports QPSK, 16QAM and 64QAM modulation
⚫
Max. transmission data rates
- DC-HSDPA: 42 Mbps (DL)
- HSUPA: 5.76 Mbps (UL)
- WCDMA: 384 kbps (DL)/ 384 kbps (UL)
RM500Q-AE&RM502Q-AE Hardware Design
1)
: Class 2 (26 dBm ± 2 dB)
2)
on n41
n1/n2/n3/n7/25/n38/n40/n41/n48*/n66/n77/
3) 3)
and 30 kHz
4)
operation modes on all
5)
:
5)
:
5)
:
5G Module Series
the 5G band
