5.3. Antenna Connectors
5.3.1. Antenna Connector Location
RM500Q-AE and RM502Q-AE have four antenna connectors each: ANT0, ANT1, ANT2 and
ANT3_GNSSL1, which are shown as below.
RM500Q-AE&RM502Q-AE_Hardware_Design
Autonomous
XTRA enabled
Autonomous
XTRA enabled
Autonomous
@ open sky
ANT0 ANT1 ANT2
Figure 28: RM500Q-AE Antenna Connectors
RM500Q-AE&RM502Q-AE Hardware Design
ANT3_GNSSL1
5G Module Series
