It is recommended to use a host GPIO to control FULL_CARD_POWER_OFF#. A simple reference circuit
is illustrated in the following figure.
Host
NOTE: The voltage of pin 6 should be no less than 1.19V when it is at HIGH level.
The timing of turn-on scenario is illustrated by the following figure.
VCC
RESET#
FCPO#
RFFE_VIO_1V8
USIM1_VDD
Module Status
Table 9: Trun-on Timing of the Module
Symbol Min.
T 0 ms
power-on
RM500Q-AE&RM502Q-AE_Hardware_Design
1.8 V or 3.3 V
GPIO
Figure 8: Turn on the Module with a Host GPIO
Module power-on or insertion detection
System turn-on and booting
68 ms
Inactive
T T
power-on turn-on
Figure 9: Turn-on Timing of the Module
Typ. Max.
20 ms -
RM500Q-AE&RM502Q-AE Hardware Design
FULL_CARD_POWER_OFF#
20 s
System booting
T
booting
Comment
System power-on time depending on the host.
