Wiring diagram without vehicle takeover
Refer to the "Pre-installation and application warnings" for important information and the description of each special note referenced in the diagram (
(+) Starter: Pin 18
Keyless Access
Control Unit
12 11 10 9 8 7
(gray connector )
24 23 22 21 20 19
(+) Accessory 1:
Pin 24
(+) Ignition: White or Blue, pin 11
(+) Starter Output
(+) Accessory Output
(+) Ignition Input
(-) Hood Input
(+) 12V Input
(-) Ground
(AC) Tach Input
(-) Parking Lights Output
Headlight Switch
(blue or white connector)
D2D Port
6 5
12 11 10
(-) Parking Lights:
Pin 11
8 403.HONDA9 2.03 2014 Acura RLX (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
2
1
6 5 4 3 2 1
18 17 16 15 14 13
F-CAN High: White or Green, pin 4
F-CAN Low: Pin 5
Hood Pin
4 3 2 1
9 8 7
(-) Parking Lights:
OR
Pin 8
Keyless Acces
Control Unit
1
(Refer to the Vehicle
connections section for the
location of this unit.)
(+) 12V: White
or Red, pin 14
14
Ignition Interrupt:
Yellow or Blue, pin 28
Cut
HS CAN High 2: Tan/Black: 3
HS CAN Low 2: Tan: 4
HS CAN High 1: Orange/Green: 5
HS CAN Low 1: Orange/Brown: 6
Ignition Interr. (veh. side): Yellow: 8
Ignition Interr. (conn. side): Orange/Yellow: 9
(-) PTS Output: Red/Black: 4
(AC) Tach Output: Violet/White: 5
Immobilizer Data: Yellow/Black: 10
(-) PTS: Pin 8
Immo. Data: Pin 21
2
Keyless Access
13 12 11 10 9 8 7 6 5 4 3 2 1
Control Unit
28
27 26 25 24 23 22 2 1 20 19 18 17 16 15
(tan or gray connector)
B-CAN Low: Pin 7
B-CAN High: Pin 6
).
XKD2D65
