Vehicle Takeover - Additional Connections - Directed DIRECTECHS DB3 Installation Manual

Vehicle takeover addtional connections
Refer to the "Pre-installation and application warnings" for important information and the description of each special note referenced in the diagram (
(+) Ignition Interrupt 3:
Red or Lt.Green, pin 10
(+) 12V
Input
5A Fuse
(-) Ground
D2D Port
7 403.HONDA9 2.03 2014 Acura RLX (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
Keyless Acces Control Unit
(Refer to the Vehicle connections section
for the location of this unit.)
2
Keyless Access Control Unit
(Gray connector)
1
12 11 10 9 8 7 6 5 4 3 2 1
24 23 22 21 20 19 18 17 16 15 14 13
(+) Ignition Interrupt 2: Yellow or Green, pin 8
(+) Ignition Interrupt 4:
Red or Black, pin 22
8616 8616
Mini Mini
Cut Cut
Relay Relay
87 87a 87
85 86 85
30 30
1A Diode (1N4002+) 1A Diode (1N4002+)
1
Keyless Access Control Unit
(tan or gray connector)
2
14 13 12 11 10
(+) 12V:
28 27 26 25 24 23
White
or Red,
Ignition Interrupt 1:
pin 14
Yellow or Blue, pin 28
8616
Mini
Cut Cut
Relay
87a 87 87a
86 85 86
30
1A Diode (1N4002+)
9 8 7 6 5 4 3 2 1
22 2 1 20 19 18 17 16 15
8616 wire and color reference
Orange
8616
Brown
Mini
Relay
87 87a
Yellow
Black
85 86
30
1A Diode (1N4002+)
(-) Takeover Output: Green/Black: 2
).
8616
Mini
Relay
87 87a
Red
85 86
30
