A gas supply pressure above 2.5 bar / 36 psi will result in unit damage. It is thus important to check the
real output pressure of gas bottles, sets of gas bottles or central gas supplies before connecting the gas
hose to the incubator.
Wrong sequence when connecting gas supply.
Damage to the unit.
∅ Do NOT connect the unit before setting the pressure.
When connecting, observe this sequence:
1. Open the main tap of gas bottle or gas supply
2. Set the output pressure on the pressure scale
3. Connect the gas hose to the incubator
Replacing gas bottles: Remove the hose connection to the incubator. Then open the main valve of the
bottle pressure reducer. Check the output pressure on the second manometer; if appropriate, set it to 2.5
bar / 36 psi maximum. Only then can you establish the hose connection to the incubator.
The recovery times of the gas concentrations inside the chamber after opening the door are
indicated in the technical data (chap. 18.4) and refer to a connection pressure of 2.0 bar / 29
psi. Decreasing supply pressure will result in longer recovery times.
4.5

Electrical connection

• The CO
incubator C 150 has a fixed power supply connection cable 1800 mm / 70.87 inches in
2
length and a shock-proof plug. Tension 230 V (1N~) +/- 10%, 50/60 Hz
• Prior to connection and start-up, check the power supply voltage. Compare the values to the specified
data located on the unit's type plate (centrally located at the bottom of the left-hand side of the unit,
see chap. 1.4)
• When connecting, please observe the regulations specified by the local electricity supply company
and as well as the VDE directives (for Germany)
• Pollution degree (acc. to IEC 61010-1): 2
• Over-voltage category (acc. to IEC 61010-1): II
Danger of incorrect power supply voltage.
Damage to the equipment.
Check the power supply voltage before connection and start-up.
Compare the power supply voltage with the data indicated on the type plate.
See also electrical data (chap. 18.4).
To completely separate the unit from the power supply, you must disconnect the power plug.
Install the unit in a way that the power plug is easily accessible and can be easily pulled in
case of danger.
