Binder APT.line C 150 Operating Manual page 11

Nominal temperature 190 °C
374°F
Enclosure protection IP 20
Temp. safety device DIN 12880
Class 3.1
Art. No. 9040-0078
Project No.
Indications of the type plate
Nominal temperature
Enclosure protection
Temp. safety device
Class
Art. No.
Project No.
1,40 kW
230 V 1 N ~
6,1 A
50/60 Hz
C 150
Serial No. 00-00000
Symbol on the type plate
(C 150-UL only)
LABORATORY EQUIPMENT
43KM
C 150 (E2) 06/2011
1,40 kW
230 V 1 N ~
6,1 A
50/60 Hz
US PATS 4585923 / 5222612 / 5309981
5405194 / 5601143 / 5773287 / 6079403
D 78532 Tuttlingen / Germany
Tel. + 49 (0) 7462/ 2005-0
Internet: www.binder-world.com
Figure 6: Type plate C 150 (standard unit)
Information
190 °C Nominal temperature
374°F
IP 20 IP type of protection 20 acc. to EN 60529
DIN 12880 Temperature safety device acc. to standard DIN 12880
3.1 Temperature safety device, class 3.1
9040-0078 Art. No. 9040-0078
--- (Special application acc. to project no.)
Nominal power 1.40 kW
Nominal voltage 230 V ± 10 %, single-phase unit
Nominal current 6.1 Amp
Power frequency 50/60 Hz
Model C 150
Serial No. 00-00000
Information
CE conformity marking
Electrical and electronic equipment manufactured / placed on
the market in the EC after 13 August 2005 and to be disposed of
in a separate collection according to directive 2002/96/EC on
waste electrical and electronic equipment (WEEE).
VDE-GS certification mark
The equipment is certified in the GOST R certification system of
GOSTSTANDARD Russia.
The equipment is certified by Underwriters Laboratories Inc.®
according to standards UL 61010A-1, UL 61010A-2-10, CSA
C22.2 No. 1010.1-92, and CSA C22.2 No. 1010.2.010-94.
C 150 Serial No. 00-00000
Made in Germany
page 11/78
