2.3 Connection panel at the rear of the unit
(11)
(12)
(13)
(14)
(15)
Figure 8: Rear connection panel C 150
(11) Power cable
(12) Miniature fuse
(13) Connection socket for zero-voltage relay alarm contact
(14) Quick acting closure socket for CO
gas bottle
2
(15) Ethernet interface for computer communication (option)
2.4
Triangle instrument panel C 150
(2)
Figure 9: Triangle instrument panel with RP1 controller
(2)
Main power switch with protruding plastic shield (protection against turning off unintentionally)
C 150 (E2) 06/2011
page 16/78
