The equipment has been leveled and calibrated before leaving factory. However, the leveling plane may be damaged
due to the vibration generated during transportation. It is recommended to perform leveling before the first printing.
There are two leveling modes: auxiliary leveling mode and manual leveling mode. In the auxiliary leveling mode, all
execution will be completed with the help of the extruder sensor and auxiliary prompts. When the function option is in
the manual mode, the platform leveling in the auxiliary mode will not activate the sensor function.
In total, the equipment contains the following leveling calibrations: Platform Leveling, Calibration XY, Calibration Z and
Auto level;
Please operate in the following order:
1. Click [Tools] and [Level Calibration] on the touch screen;
2. Select the auxiliary mode for leveling and calibration;
3. The extruder sensor calibration has been set before leaving factory, so there is no need to operate again; Click
platform leveling and operate following the prompts on the screen.
4. Perform Z-axis calibration and operate following the prompts on the screen;
5. The X, Y axis have been calibrated before leaving factory, so there is no need to operate again;
6. The whole leveling and calibration is completed.
9-point leveling function: when the printing flatness is still poor after the platform leveling and XY/Z axis calibration,
this function can be used to compensate for better flatness;
Manual leveling mode: Execute platform leveling, Z-axis calibration and X, Y axis calibration in turn. This is a complete
set of leveling and calibration operation procedures.
