Block Diagram - Altera DE5-NET User Manual

 System Monitor and Control

Temperature sensor

Fan control
 Power

PCI Express 6-pin power connector, 12V DC Input

PCI Express edge connector power
 Mechanical Specification

PCI Express full-height and 3/4-length
1 . 3 B l o c k
1 . 3 B l o c k
F igure 1-1 shows the block diagram of the DE5-Net board. To provide maximum flexibility for the
9 4 H 9 4 H
users, all key components are connected with the Stratix V GX FPGA device. Thus, users can
configure the FPGA to implement any system design.
